Aluminum Power Metal Shell Case RX24 10W 25W 50W 100W 200W 300W wirewound precharge resistor

Name: Aluminum Power Metal Shell Case RX24 10W 25W 50W 100W 200W 300W wirewound precharge resistor
Brand: BONENS
Price: 1 USD

Quality Aluminum Power Metal Shell Case RX24 10W 25W 50W 100W 200W 300W wirewound precharge resistor for sale

Brand Name : BONENS

Model Number : RX24

Place of Origin : China

Rated Power : 5W~50W

Operating voltage range : <1.5kV

Rated resistance range : 0.1Ω~10KΩ

Maximum withstand voltage : 3000V

Temperature drift range : ≤400ppm/℃

Working temperature range : -55℃～+275℃

Contact Now

Aluminum Power Metal Shell Case RX24 10W 25W 50W 100W 200W 300W wirewound precharge resistor

Product Description
The surface of the gold aluminum shell resistor has a heat dissipation groove, small size, large power, high temperature
resistance, strong overload capacity, weather resistance, high precision, standard low inductive resistance, high stability, strong architecture, and its flexibility is good for multiple combination options, which is conducive to mechanical protection and easy installation and use.

Test items	Standard	Test Methods
Short time overload	±5%,±2%,±1%	2.5 times power/5 seconds
Temperature coefficient	±200PPM/°C	Test temperature:indoors temp.100°C
Resistance to solder heat	±1%	Solder temp:350±10°C time:3 seconds
Dielectric withstanding voltage	No breakdown or flashover	500V for 60 seconds
Humidity Load Life	±0.5%	1.5hr ON,0.5hr OFF at 40±2°C,90-95&RH for 1000hrs
Load Life	±2.0%	Rated voltage 1.5hrON,0.5hr OFF at 25°C for 1000hrs
Solderability	At least 95% coerage	235±5°C for 2±0.5 seconds

01
Complete specifications
Customized on demand
Reliable quality

02
Insulation performance
Good insulation
Good pressure resistance
High heat dissipation power
High stability

03
Aluminum shell
Aluminum alloy
The surface is oxidized
Heat dissipation grooves
High power
High temperature resistance
Complete fusion welding structure

04
Resistance bar
Constantan wire or nickel Luo
Alloy wire depends on the
Resistance value
Comply with ROHS standard and
LEAD-FREE lead-free standard

SiChuan Qixing Elctronics Co., Ltd is a specialized enterprise engaging in trimming potentiometers, wire-wound potentiometer series, wire-wound resistor series, and RIG High power resistors. It is a high-tech enterprise appraised by state. Our products under the "BONENS" brand that have been widely applied in the fields of instruments, meters and apparatuses, post and telecommunications, electricity power, railway signals, aviation and aerospace.
We have attained ISO9001 certificate, and passed the TUV and RoHS, which adheres to the environmental standards of the EU. With excellent product quality, advanced facility, abundant technology, strict management and good service, win customers’ high praise and faith! Besides our own main products, we are also pleased to offer customers other extra products and service as their requirement, such as any other consumer electronics and quality supervision commissioner in China.

1. Are you a factory or trading company?
A1: We are a factory, we can guarantee our price is first-hand. All products are characterized by high performance and competitive
price.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Potentiometer,Resistor,EMI Filter,Knob,Switch
4. why should you buy from us not from other suppliers?
Our company is establsihed in 2005 ,which mainly develops and manufactures different types of potentiometer,ac dc noise filter,and
ceramic power resistor and is a professional manufacturer ensuring high quality, best services and best price.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union,Cash;
Language Spoken:English,Chinese
